Sensor: S_2x4T_13, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | W52_DOLQC8T | 62D |
ROC1 | W52_DOLQC8T | 62A |
ROC2 | W52_DOLQC8T | 61C |
ROC3 | W52_DOLQC8T | 61B |
ROC4 | W52_DOLQC8T | 45B |
ROC5 | W52_DOLQC8T | 45D |
ROC6 | W52_DOLQC8T | 46A |
ROC7 | W52_DOLQC8T | 46B |
Ibias_DAC, Ibias_DAC Data | 144 | 146 | 150 | 154 | 146 | 154 | 156 | 154 |
Vana, VanaData | 146 | 145 | 145 | 139 | 143 | 145 | 130 | 150 |
CalDelData and plots | 94 | 69 | 97 | 81 | 78 | 100 | 81 | 86 |
VthrCompData and plots | 85 | 90 | 79 | 90 | 89 | 83 | 86 | 89 | Depletion Voltage is -44 and suggested operational voltage is -84
TestDdata ,TestD Plots | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Noise MAP at VMAX
Efficiency MAP
EXTRA DACs for NOISE
VHldDe | 95 | 100 | 90 | 105 | 100 | 90 | 105 | 95 |
Vsf | 150 | 150 | 145 | 145 | 145 | 145 | 140 | 150 |
VoffsetOp | 100 | 100 | 95 | 120 | 115 | 110 | 110 | 120 |
VIbias_PH | 100 | 100 | 105 | 100 | 100 | 105 | 100 | 100 |
Comment (if any):
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 3:40 PM
