P_2x4T_120

P_2x4T_120_A

Parts committed by Bolla Gino on date 10/29/2006

Part	ID
BBM	BBM_120-2x4T
VHDI	2x4_253

ROC ROC wafer Label

ROC0 W20_XP4K3AT 56C

ROC1 W20_XP4K3AT 56B

ROC2 W20_XP4K3AT 56A

ROC3 W20_XP4K3AT 55D

ROC4 W20_XP4K3AT 75C

ROC5 W20_XP4K3AT 75D

ROC6 W20_XP4K3AT 76A

ROC7 W20_XP4K3AT 76B

ROC	ROC wafer	Label
ROC0	W20_XP4K3AT	56C
ROC1	W20_XP4K3AT	56B
ROC2	W20_XP4K3AT	56A
ROC3	W20_XP4K3AT	55D
ROC4	W20_XP4K3AT	75C
ROC5	W20_XP4K3AT	75D
ROC6	W20_XP4K3AT	76A
ROC7	W20_XP4K3AT	76B

Inspected by Arndt Kirk on date 10/31/2006

LR_dev 0.041

LL_dev 0.024

FINAL COMMENT by Arndt Kirk No assembly problems. No wirebond problem.

PLAQUETTE made READY for testing on 10/31/2006 by Arndt Kirk

PLAQUETTE TESTED on 2006-11-01 by Isaac Childres

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	148	158	152	153	148	172	154	151
Vana	121	118	125	125	117	130	129	120
Cal_Del	74	91	97	92	94	86	84	87
Vthrs_Comp	90	74	63	74	69	76	83	70
Unbumped	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-01

Plaquette assigned to panel P3R_042
