Sensor: S_2x4T_00, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC	ROC wafer	Label
ROC0	XG4KFCT	75D
ROC1	XG4KFCT	75C
ROC2	XG4KFCT	74D
ROC3	XG4KFCT	74C
ROC4	XG4KFCT	68A
ROC5	XG4KFCT	68B
ROC6	XG4KFCT	73C
ROC7	XG4KFCT	73D

Depletion Voltage is -52 and suggested operational voltage is -92

Ibias_DAC, Ibias_DAC Data	144	154	130	134	142	142	148	134
Vana, VanaData	138	131	134	127	143	127	118	131
CalDelData and plots	72	83	95	83	73	83	72	78
VthrCompData and plots	89	82	68	81	92	86	80	71
TestDdata ,TestD Plots	0	0	0	4	0	1	0	0
LightData ,Light Plots	0	0	0	0	0	1	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD

Noise MAP

Efficiency MAP

ROC0 NOISE			MEAN = 6.540922 SIGMA = 0.466177
ROC1 NOISE			MEAN = 4.989892 SIGMA = 0.383682
ROC2 NOISE			MEAN = 4.969781 SIGMA = 0.385626
ROC3 NOISE			MEAN = 5.503491 SIGMA = 0.413862
ROC4 NOISE			MEAN = 5.559755 SIGMA = 0.450612
ROC5 NOISE			MEAN = 4.353497 SIGMA = 0.333252
ROC6 NOISE			MEAN = 5.185774 SIGMA = 0.420963
ROC7 NOISE			MEAN = 4.846379 SIGMA = 0.370430

Comment (if any):

End testing time: 8:59 AM
