P_2x4B_129

P_2x4B_129_A

Parts committed by Bolla Gino on date 12/21/2006

Part	ID
BBM	BBM_129-2x4B
VHDI	2x4_342

ROC ROC wafer Label

ROC0 W32_XA4K5NT 12C

ROC1 W32_XA4K5NT 12A

ROC2 W32_XA4K5NT 11D

ROC3 W32_XA4K5NT 11A

ROC4 W31_X44K5UT 76D

ROC5 W31_X44K5UT 61D

ROC6 W31_X44K5UT 62A

ROC7 W31_X44K5UT 62B

ROC	ROC wafer	Label
ROC0	W32_XA4K5NT	12C
ROC1	W32_XA4K5NT	12A
ROC2	W32_XA4K5NT	11D
ROC3	W32_XA4K5NT	11A
ROC4	W31_X44K5UT	76D
ROC5	W31_X44K5UT	61D
ROC6	W31_X44K5UT	62A
ROC7	W31_X44K5UT	62B

Inspected by Kirk Arndt on date 2007-01-09

LR_dev 0.025

LL_dev 0.063

FINAL COMMENT by Kirk Arndt No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 2007-01-09 by Kirk Arndt

PLAQUETTE TESTED on 2007-01-10 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	130	138	126	132	148	134	138	140
Vana	122	114	113	117	130	133	129	112
Cal_Del	102	85	92	88	66	77	92	82
Vthrs_Comp	65	82	70	66	81	70	74	75
Unbumped	0	0	0	0	0	0	0	1
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	1

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY TO BE SHIPPED

Shipped on date 2007-01-22

Plaquette assigned to panel P4R_046
