Sensor: S_2x4B_11, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | W21_XA4KFIT | 57B |
ROC1 | W21_XA4KFIT | 57A |
ROC2 | W21_XA4KFIT | 56D |
ROC3 | W21_XA4KFIT | 56C |
ROC4 | W21_XA4KFIT | 49B |
ROC5 | W21_XA4KFIT | 49C |
ROC6 | W21_XA4KFIT | 30A |
ROC7 | W21_XA4KFIT | 30B |
Ibias_DAC, Ibias_DAC Data | 142 | 137 | 148 | 147 | 155 | 145 | 136 | 124 |
Vana, VanaData | 116 | 127 | 132 | 126 | 127 | 135 | 125 | 101 |
CalDelData and plots | 96 | 70 | 77 | 77 | 80 | 82 | 88 | 95 |
VthrCompData and plots | 68 | 84 | 70 | 78 | 77 | 76 | 70 | 58 | Depletion Voltage is -46 and suggested operational voltage is -86
TestDdata ,TestD Plots | 5 | 0 | 5 | 0 | 28 | 23 | 37 | 3 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): TestD showed bad pixels around the edges, with a couple dead pixels, but it looks okay anyway.
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 4:29 PM
