Sensor: S_2x4B_11, Data for leakage current measurement , and plot on overall it is a BAD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | W32_XA4K5NT | 04C |
ROC1 | W32_XA4K5NT | 04B |
ROC2 | W32_XA4K5NT | 04A |
ROC3 | W32_XA4K5NT | 03D |
ROC4 | W31_X44K5UT | 68A |
ROC5 | W31_X44K5UT | 51A |
ROC6 | W31_X44K5UT | 51B |
ROC7 | W31_X44K5UT | 51C |
Ibias_DAC, Ibias_DAC Data | 132 | 140 | 142 | 132 | 144 | 144 | 142 | 142 |
Vana, VanaData | 125 | 146 | 131 | 125 | 132 | 127 | 131 | 134 |
CalDelData and plots | 71 | 70 | 78 | 73 | 88 | 67 | 67 | 93 |
VthrCompData and plots | 79 | 82 | 83 | 81 | 74 | 82 | 74 | 69 | Depletion Voltage is -48 and suggested operational voltage is -88
TestDdata ,TestD Plots | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): GOOD
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 1:22 PM
