P_2x4B_085

P_2x4B_085_A

Parts committed by Bolla Gino on date 10/30/2006

Part	ID
BBM	BBM_085-2x4B
VHDI	2x4_254

ROC ROC wafer Label

ROC0 W18_XJ4K3FT 27D

ROC1 W18_XJ4K3FT 27A

ROC2 W18_XJ4K3FT 26D

ROC3 W18_XJ4K3FT 26C

ROC4 W20_XP4K3AT 04B

ROC5 W20_XP4K3AT 03D

ROC6 W20_XP4K3AT 03C

ROC7 W20_XP4K3AT 03B

ROC	ROC wafer	Label
ROC0	W18_XJ4K3FT	27D
ROC1	W18_XJ4K3FT	27A
ROC2	W18_XJ4K3FT	26D
ROC3	W18_XJ4K3FT	26C
ROC4	W20_XP4K3AT	04B
ROC5	W20_XP4K3AT	03D
ROC6	W20_XP4K3AT	03C
ROC7	W20_XP4K3AT	03B

Inspected by Graves Durand on date 11/6/2006

LR_dev 0.038

LL_dev 0.051

FINAL COMMENT by Graves Durand No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/6/2006 by Graves Durand

PLAQUETTE TESTED on 2006-11-06 by Cameron McKinney

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	148	170	158	156	162	148	146	151
Vana	133	126	114	126	125	127	118	128
Cal_Del	76	79	86	82	101	94	87	93
Vthrs_Comp	84	80	70	74	64	75	73	80
Unbumped	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-13

Plaquette assigned to panel P4L_014
