![[IMAGE] of](P_2x4B_011_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 510 V |
![[IMAGE] of](P_2x4B_011_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_011-2x4B |
| VHDI | 2x4_345 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | X74JP0T | 51C |
| ROC1 | X74JP0T | 51A |
| ROC2 | X74JP0T | 68D |
| ROC3 | X74JP0T | 68C |
| ROC4 | X74JP0T | 47B |
| ROC5 | X74JP0T | 47C |
| ROC6 | X74JP0T | 47D |
| ROC7 | X74JP0T | 48A |
Inspected by Arndt Kirk on date 2006-06-29
| LR_dev | 0.013 |
| LL_dev | 0.058 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-06-29 by Arndt Kirk
PLAQUETTE TESTED on 2006-7-05 by Petra Merkel
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 152 | 163 | 170 | 184 | 172 | 168 | 164 | 159 | |
| Vana | 138 | 132 | 134 | 133 | 121 | 128 | 130 | 118 | |
| Cal_Del | 96 | 83 | 92 | 83 | 86 | 80 | 89 | 90 | |
| Vthrs_Comp | 72 | 76 | 74 | 77 | 79 | 80 | 72 | 72 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_011_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_011_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_011_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_011_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_011_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_011_Ano-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-07-10
