Sensor: S_2x4B_00, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XG4KFCT | 67B |
| ROC1 | XG4KFCT | 67A |
| ROC2 | XG4KFCT | 66B |
| ROC3 | XG4KFCT | 66A |
| ROC4 | XG4KFCT | 63B |
| ROC5 | XG4KFCT | 64B |
| ROC6 | XG4KFCT | 65A |
| ROC7 | XG4KFCT | 65B |
| Ibias_DAC, Ibias_DAC Data | 142 | 144 | 126 | 126 | 122 | 132 | 142 | 130 |
| Vana, VanaData | 140 | 163 | 122 | 126 | 130 | 127 | 128 | 142 |
| CalDelData and plots | 80 | 57 | 95 | 92 | 97 | 69 | 92 | 90 |
| VthrCompData and plots | 86 | 88 | 83 | 84 | 75 | 92 | 74 | 72 | Depletion Voltage is -10 and suggested operational voltage is -50 Bad laser.
