Sensor: S_2x3T_17, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | KFNG13T | 58D |
ROC1 | KFNG13T | 37D |
ROC2 | KFNG13T | 57D |
ROC3 | KFNG13T | 17C |
ROC4 | KFNG13T | 68D |
ROC5 | KFNG13T | 58B |
Ibias_DAC, Ibias_DAC Data | 170 | 146 | 160 | 164 | 162 | 160 |
Vana, VanaData | 148 | 127 | 146 | 139 | 133 | 145 |
CalDelData and plots | 71 | 87 | 76 | 73 | 96 | 62 |
VthrCompData and plots | 92 | 77 | 85 | 83 | 76 | 84 | Depletion Voltage is -46 and suggested operational voltage is -86
TestDdata ,TestD Plots | 0 | 0 | 1 | 0 | 0 | 0 |
LightData ,Light Plots | 0 | 2 | 2 | 1 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Noise MAP
Efficiency MAP
EXTRA DACs for NOISE
VHldDe | 95 | 120 | 100 | 110 | 120 | 95 |
Vsf | 145 | 135 | 150 | 140 | 135 | 140 |
VoffsetOp | 105 | 75 | 80 | 95 | 70 | 90 |
VIbias_PH | 100 | 105 | 105 | 95 | 100 | 95 |
Comment (if any): GOOD
This Device have been tested 1Times prior to this one and here are the links to the previous tests:End testing time: 1:11 PM
