Sensor: S_2x3T_14, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W30_X74K5RT | 68C |
| ROC1 | W30_X74K5RT | 68B |
| ROC2 | W30_X74K5RT | 68A |
| ROC3 | W30_X74K5RT | 47A |
| ROC4 | W30_X74K5RT | 47B |
| ROC5 | W30_X74K5RT | 47C |
| Ibias_DAC, Ibias_DAC Data | 146 | 144 | 138 | 144 | 128 | 136 |
| Vana, VanaData | 137 | 133 | 115 | 149 | 116 | 150 |
| CalDelData and plots | 65 | 80 | 85 | 75 | 86 | 73 |
| VthrCompData and plots | 81 | 84 | 74 | 85 | 74 | 80 | Depletion Voltage is -46 and suggested operational voltage is -86
| TestDdata ,TestD Plots | 0 | 0 | 0 | 0 | 0 | 0 |
| LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 3 |
| Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): Okay.
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 3:38 PM
