P_2x3T_120

P_2x3T_120_A

Parts committed by Bolla Gino on date 10/30/2006

Part	ID
BBM	BBM_120-2x3T
VHDI	2x3_301

ROC ROC wafer Label

ROC0 W20_XP4K3AT 55B

ROC1 W20_XP4K3AT 54D

ROC2 W20_XP4K3AT 54C

ROC3 W20_XP4K3AT 74C

ROC4 W20_XP4K3AT 74D

ROC5 W20_XP4K3AT 75B

ROC	ROC wafer	Label
ROC0	W20_XP4K3AT	55B
ROC1	W20_XP4K3AT	54D
ROC2	W20_XP4K3AT	54C
ROC3	W20_XP4K3AT	74C
ROC4	W20_XP4K3AT	74D
ROC5	W20_XP4K3AT	75B

Inspected by Arndt Kirk on date 11/2/2006

LR_dev 0.030

LL_dev 0.026

FINAL COMMENT by Arndt Kirk No assembly problems. No wirebond problem.

PLAQUETTE made READY for testing on 11/2/2006 by Arndt Kirk

PLAQUETTE TESTED on 2006-11-02 by Cameron McKinney

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	156	165	155	158	163	155
Vana	131	140	127	109	117	128
Cal_Del	88	83	81	85	90	72
Vthrs_Comp	76	85	72	74	80	80
Unbumped	0	0	0	0	0	0
Dead	0	0	0	0	0	0
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-03

Plaquette assigned to panel P4R_066
