P_2x3B_903

R_2x3B_903_C

Parts committed by Bolla Gino on date 01/01/2001

Part	ID
BBM	UNKNOWN
VHDI	UNKNOWN

ROC ROC wafer Label

ROC0 UNKNOWN UNKNOWN

ROC1 UNKNOWN UNKNOWN

ROC2 UNKNOWN UNKNOWN

ROC3 UNKNOWN UNKNOWN

ROC4 UNKNOWN UNKNOWN

ROC5 UNKNOWN UNKNOWN

ROC	ROC wafer	Label
ROC0	UNKNOWN	UNKNOWN
ROC1	UNKNOWN	UNKNOWN
ROC2	UNKNOWN	UNKNOWN
ROC3	UNKNOWN	UNKNOWN
ROC4	UNKNOWN	UNKNOWN
ROC5	UNKNOWN	UNKNOWN

Inspected by Bolla Gino on date 01/01/2001

LR_dev 0.000

LL_dev 0.000

PLAQUETTE GLUED with HALF PRESSURE

FINAL COMMENT by Bolla Gino

NONE

PLAQUETTE made READY for ENCAPSULATION on 01/01/2001 by Bolla Gino

PLAQUETTE encapsulated on 01/01/2001 by Bolla Gino

PLAQUETTE made READY for testing on 01/01/2001 by Bolla Gino

PLAQUETTE TESTED on 2007-10-02 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 242 V

Operational Voltage 282 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	138	148	164	154	160	154
Vana	139	131	133	134	145	170
Cal_Del	74	81	73	89	72	68
Vthrs_Comp	75	70	91	79	94	97
Unbumped	22	281	470	492	280	11
Dead	0	0	2	0	1	47
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	22	281	472	492	281	58

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

EXTRA DACs for NOISE

VHldDe	105	120	135	115	100	90
Vsf	140	135	145	140	140	155
VoffsetOp	80	70	85	95	125	110
VIbias_PH	100	105	100	100	105	105

Noise MAP at VMAX

Efficiency MAP

Noise MAP at -200 V

Efficiency MAP

PLAQUETTE READY TO BE SHIPPED
