P_2x3B_181

P_2x3B_181_C

Production testing

Date:5/16/2007

Operator: Emily Grace

start testing time:3:17 PM

Sensor: S_2x3B_18, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 KBNG0QT 67B

ROC1 KBNG0QT 67A

ROC2 KBNG0QT 67D

ROC3 KBNG0QT 27D

ROC4 KBNG0QT 18A

ROC5 KBNG0QT 28D

ROC	ROC wafer	Label
ROC0	KBNG0QT	67B
ROC1	KBNG0QT	67A
ROC2	KBNG0QT	67D
ROC3	KBNG0QT	27D
ROC4	KBNG0QT	18A
ROC5	KBNG0QT	28D

Depletion Voltage is -52 and suggested operational voltage is -92

Ibias_DAC, Ibias_DAC Data 144 164 160 156 146 162

Vana, VanaData 133 139 146 145 134 144

CalDelData and plots 86 83 78 81 73 98

VthrCompData and plots 73 79 77 86 87 79

TestDdata ,TestD Plots 0 0 0 1 1 1

LightData ,Light Plots 0 0 0 0 0 1

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	100	90	90	90	110	90
Vsf	135	145	145	145	140	145
VoffsetOp	60	100	95	95	80	90
VIbias_PH	100	100	100	100	105	105

ROC0 NOISE			MEAN = 4.711850 SIGMA = 0.363773
ROC1 NOISE			MEAN = 3.837123 SIGMA = 0.305785
ROC2 NOISE			MEAN = 4.381872 SIGMA = 0.352928
ROC3 NOISE			MEAN = 4.189213 SIGMA = 0.344079
ROC4 NOISE			MEAN = 4.651317 SIGMA = 0.376479
ROC5 NOISE			MEAN = 4.189527 SIGMA = 0.342794

Comment (if any):

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 3:42 PM

Ibias_DAC, Ibias_DAC Data	144	164	160	156	146	162
Vana, VanaData	133	139	146	145	134	144
CalDelData and plots	86	83	78	81	73	98
VthrCompData and plots	73	79	77	86	87	79
TestDdata ,TestD Plots	0	0	0	1	1	1
LightData ,Light Plots	0	0	0	0	0	1
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
