P_2x3B_159

P_2x3B_159_C

Production testing

Date:5/1/2007

Operator: mia tosi

start testing time:11:07 AM

Sensor: S_2x3B_15, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 X94KFJT 41A

ROC1 X94KFJT 12B

ROC2 X94KFJT 75B

ROC3 X94KFJT 76A

ROC4 X94KFJT 21B

ROC5 X94KFJT 12D

ROC	ROC wafer	Label
ROC0	X94KFJT	41A
ROC1	X94KFJT	12B
ROC2	X94KFJT	75B
ROC3	X94KFJT	76A
ROC4	X94KFJT	21B
ROC5	X94KFJT	12D

Depletion Voltage is -52 and suggested operational voltage is -92

Ibias_DAC, Ibias_DAC Data 134 144 130 142 138 134

Vana, VanaData 143 144 128 135 142 146

CalDelData and plots 90 83 86 86 75 83

VthrCompData and plots 85 74 65 81 82 79

TestDdata ,TestD Plots 2 0 0 1 0 1

LightData ,Light Plots 0 0 1 1 0 6

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	100	100	120	130	95	85
Vsf	145	140	140	140	140	145
VoffsetOp	75	90	65	105	95	85
VIbias_PH	100	95	100	100	105	105

ROC0 NOISE			MEAN = 4.926831 SIGMA = 0.407899
ROC1 NOISE			MEAN = 4.612258 SIGMA = 0.369112
ROC2 NOISE			MEAN = 5.450017 SIGMA = 0.425090
ROC3 NOISE			MEAN = 3.790646 SIGMA = 0.270848
ROC4 NOISE			MEAN = 5.210324 SIGMA = 0.428846
ROC5 NOISE			MEAN = 5.673269 SIGMA = 0.481671

Comment (if any): good, look roc 3

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 11:27 AM

Ibias_DAC, Ibias_DAC Data	134	144	130	142	138	134
Vana, VanaData	143	144	128	135	142	146
CalDelData and plots	90	83	86	86	75	83
VthrCompData and plots	85	74	65	81	82	79
TestDdata ,TestD Plots	2	0	0	1	0	1
LightData ,Light Plots	0	0	1	1	0	6
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
