Production testing

Date:6/7/2007

Operator: Emily Grace

start testing time:10:34 AM

Sensor: S_2x3B_14, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 DULQEDT 64D

ROC1 DULQEDT 27C

ROC2 DULQEDT 26B

ROC3 DULQEDT 16B

ROC4 DULQEDT 27D

ROC5 DULQEDT 25A

ROC	ROC wafer	Label
ROC0	DULQEDT	64D
ROC1	DULQEDT	27C
ROC2	DULQEDT	26B
ROC3	DULQEDT	16B
ROC4	DULQEDT	27D
ROC5	DULQEDT	25A

Depletion Voltage is -44 and suggested operational voltage is -84

Ibias_DAC, Ibias_DAC Data 158 158 154 156 148 154

Vana, VanaData 139 161 138 142 148 157

CalDelData and plots 102 78 86 88 87 78

VthrCompData and plots 86 92 81 84 88 92

TestDdata ,TestD Plots 1 0 2 0 1 0

LightData ,Light Plots 1 0 8 0 1 0

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	120	105	95	105	95	100
Vsf	145	155	145	145	145	155
VoffsetOp	80	115	110	95	115	105
VIbias_PH	100	100	100	105	95	100

ROC0 NOISE			MEAN = 4.469704 SIGMA = 0.361424
ROC1 NOISE			MEAN = 4.128873 SIGMA = 0.319970
ROC2 NOISE			MEAN = 4.051673 SIGMA = 0.337694
ROC3 NOISE			MEAN = 4.329114 SIGMA = 0.342895
ROC4 NOISE			MEAN = 4.134933 SIGMA = 0.323453
ROC5 NOISE			MEAN = 4.296111 SIGMA = 0.327434

Comment (if any):

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 10:56 AM

Ibias_DAC, Ibias_DAC Data	158	158	154	156	148	154
Vana, VanaData	139	161	138	142	148	157
CalDelData and plots	102	78	86	88	87	78
VthrCompData and plots	86	92	81	84	88	92
TestDdata ,TestD Plots	1	0	2	0	1	0
LightData ,Light Plots	1	0	8	0	1	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
