P_2x3B_134

P_2x3B_134_A

Production testing

Date:4/30/2007

Operator: Gino Bolla

start testing time:11:52 AM

Sensor: S_2x3B_13, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 W35_XH4K3HT 24A

ROC1 W35_XH4K3HT 23C

ROC2 W35_XH4K3HT 23B

ROC3 W35_XH4K3HT 46C

ROC4 W35_XH4K3HT 47A

ROC5 W35_XH4K3HT 47B

ROC	ROC wafer	Label
ROC0	W35_XH4K3HT	24A
ROC1	W35_XH4K3HT	23C
ROC2	W35_XH4K3HT	23B
ROC3	W35_XH4K3HT	46C
ROC4	W35_XH4K3HT	47A
ROC5	W35_XH4K3HT	47B

Depletion Voltage is -48 and suggested operational voltage is -88

Ibias_DAC, Ibias_DAC Data 134 130 136 144 144 124

Vana, VanaData 127 115 144 127 140 125

CalDelData and plots 80 87 79 85 85 100

VthrCompData and plots 83 66 76 80 75 77

TestDdata ,TestD Plots 0 0 0 0 0 0

LightData ,Light Plots 0 0 0 0 0 0

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	125	140	95	115	115	140
Vsf	140	130	145	140	145	140
VoffsetOp	75	70	95	75	90	70
VIbias_PH	100	95	100	100	100	95

ROC0 NOISE			MEAN = 5.187080 SIGMA = 0.406153
ROC1 NOISE			MEAN = 4.554306 SIGMA = 0.369356
ROC2 NOISE			MEAN = 5.088695 SIGMA = 0.431360
ROC3 NOISE			MEAN = 3.881023 SIGMA = 0.312043
ROC4 NOISE			MEAN = 4.412763 SIGMA = 0.355089
ROC5 NOISE			MEAN = 5.339267 SIGMA = 0.435522

Comment (if any): GOOD

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 12:12 PM

Ibias_DAC, Ibias_DAC Data	134	130	136	144	144	124
Vana, VanaData	127	115	144	127	140	125
CalDelData and plots	80	87	79	85	85	100
VthrCompData and plots	83	66	76	80	75	77
TestDdata ,TestD Plots	0	0	0	0	0	0
LightData ,Light Plots	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
