P_2x3B_132

P_2x3B_132_A-1

Production testing

Date:6/5/2007

Operator: Emily Grace

start testing time:9:44 AM

Sensor: S_2x3B_13, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 W45_D3LQFLT 45D

ROC1 W45_D3LQFLT 45C

ROC2 W45_D3LQFLT 44D

ROC3 W45_D3LQFLT 22B

ROC4 W45_D3LQFLT 22D

ROC5 W45_D3LQFLT 23C

ROC	ROC wafer	Label
ROC0	W45_D3LQFLT	45D
ROC1	W45_D3LQFLT	45C
ROC2	W45_D3LQFLT	44D
ROC3	W45_D3LQFLT	22B
ROC4	W45_D3LQFLT	22D
ROC5	W45_D3LQFLT	23C

Depletion Voltage is -42 and suggested operational voltage is -82

Ibias_DAC, Ibias_DAC Data 174 160 156 148 158 154

Vana, VanaData 157 144 149 143 158 142

CalDelData and plots 71 78 85 80 76 97

VthrCompData and plots 91 91 86 88 93 82

TestDdata ,TestD Plots 1 0 0 8 45 0

LightData ,Light Plots 0 0 0 0 0 0

Pass/Fail TestD GOOD GOOD GOOD GOOD BAD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	105	100	95	95	95	95
Vsf	155	145	145	145	155	145
VoffsetOp	125	115	105	120	95	95
VIbias_PH	100	95	100	100	100	100

ROC0 NOISE			MEAN = 3.282007 SIGMA = 0.242215
ROC1 NOISE			MEAN = 3.760632 SIGMA = 0.305291
ROC2 NOISE			MEAN = 4.075401 SIGMA = 0.314489
ROC3 NOISE			MEAN = 3.985884 SIGMA = 0.334510
ROC4 NOISE			MEAN = 4.498962 SIGMA = 0.351857
ROC5 NOISE			MEAN = 4.282074 SIGMA = 0.341984

Comment (if any):

This Device have been tested 1Times prior to this one and here are the links to the previous tests:

P_2x3B_132_A.html,

End testing time: 10:10 AM

Ibias_DAC, Ibias_DAC Data	174	160	156	148	158	154
Vana, VanaData	157	144	149	143	158	142
CalDelData and plots	71	78	85	80	76	97
VthrCompData and plots	91	91	86	88	93	82
TestDdata ,TestD Plots	1	0	0	8	45	0
LightData ,Light Plots	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	BAD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
