P_2x3B_102

P_2x3B_102_A

Production testing

Date:2/21/2007

Operator: Isaac Childres

start testing time:3:35 PM

Sensor: S_2x3B_10, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 W29_X64K5ST 30C

ROC1 W29_X64K5ST 30B

ROC2 W29_X64K5ST 49C

ROC3 W29_X64K5ST 22D

ROC4 W29_X64K5ST 23A

ROC5 W29_X64K5ST 23B

ROC	ROC wafer	Label
ROC0	W29_X64K5ST	30C
ROC1	W29_X64K5ST	30B
ROC2	W29_X64K5ST	49C
ROC3	W29_X64K5ST	22D
ROC4	W29_X64K5ST	23A
ROC5	W29_X64K5ST	23B

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data 128 142 142 138 128 128

Vana, VanaData 138 125 135 131 129 116

CalDelData and plots 69 86 84 73 81 79

VthrCompData and plots 83 82 71 70 77 81

TestDdata ,TestD Plots 1 2 0 0 0 0

LightData ,Light Plots 0 0 0 0 0 0

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	115	135	90	120	120	180
Vsf	140	140	140	140	140	140
VoffsetOp	60	90	90	75	80	75
VIbias_PH	105	100	105	105	100	95

ROC0 NOISE			MEAN = 5.771848 SIGMA = 0.465750
ROC1 NOISE			MEAN = 4.642577 SIGMA = 0.365020
ROC2 NOISE			MEAN = 4.496691 SIGMA = 0.337935
ROC3 NOISE			MEAN = 5.402688 SIGMA = 0.418945
ROC4 NOISE			MEAN = 5.166677 SIGMA = 0.419949
ROC5 NOISE			MEAN = 4.707492 SIGMA = 0.388760

Comment (if any): Good

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 3:53 PM

Ibias_DAC, Ibias_DAC Data	128	142	142	138	128	128
Vana, VanaData	138	125	135	131	129	116
CalDelData and plots	69	86	84	73	81	79
VthrCompData and plots	83	82	71	70	77	81
TestDdata ,TestD Plots	1	2	0	0	0	0
LightData ,Light Plots	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
