Sensor: S_2x3B_08, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | W32_XA4K5NT | 64C |
ROC1 | W32_XA4K5NT | 64B |
ROC2 | W32_XA4K5NT | 64A |
ROC3 | W32_XA4K5NT | 46D |
ROC4 | W32_XA4K5NT | 47A |
ROC5 | W32_XA4K5NT | 47B |
Ibias_DAC, Ibias_DAC Data | 142 | 139 | 132 | 141 | 133 | 139 |
Vana, VanaData | 145 | 139 | 128 | 139 | 138 | 112 |
CalDelData and plots | 89 | 69 | 88 | 83 | 90 | 80 |
VthrCompData and plots | 79 | 85 | 71 | 79 | 74 | 67 | Depletion Voltage is -52 and suggested operational voltage is -92
TestDdata ,TestD Plots | 0 | 0 | 0 | 0 | 0 | 0 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): Perfect plaquette.
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 1:21 PM
