P_2x3B_062

P_2x3B_062_C

Production testing

Date:4/6/2007

Operator: Cameron McKinney

start testing time:11:31 AM

Sensor: S_2x3B_06, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 XH4KFBT 14B

ROC1 XH4KFBT 18D

ROC2 XH4KFBT 37C

ROC3 XH4KFBT 16B

ROC4 XH4KFBT 27D

ROC5 XH4KFBT 24C

ROC	ROC wafer	Label
ROC0	XH4KFBT	14B
ROC1	XH4KFBT	18D
ROC2	XH4KFBT	37C
ROC3	XH4KFBT	16B
ROC4	XH4KFBT	27D
ROC5	XH4KFBT	24C

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data 134 132 134 140 142 134

Vana, VanaData 122 111 149 132 133 148

CalDelData and plots 82 77 93 84 91 89

VthrCompData and plots 67 62 78 81 77 81

TestDdata ,TestD Plots 0 0 1 0 0 5

LightData ,Light Plots 0 0 1 0 0 5

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	110	160	100	125	125	95
Vsf	135	140	150	140	140	140
VoffsetOp	70	80	110	65	70	80
VIbias_PH	105	95	105	105	105	100

ROC0 NOISE			MEAN = 5.103503 SIGMA = 0.402182
ROC1 NOISE			MEAN = 4.612589 SIGMA = 0.370073
ROC2 NOISE			MEAN = 5.064903 SIGMA = 0.414016
ROC3 NOISE			MEAN = 5.476130 SIGMA = 0.457160
ROC4 NOISE			MEAN = 5.216347 SIGMA = 0.412935
ROC5 NOISE			MEAN = 4.864866 SIGMA = 0.388627

Comment (if any): Good.

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 11:50 AM
