P_2x3B_043

P_2x3B_043_A

Parts committed by Bolla Gino on date 11/3/2006

Part	ID
BBM	BBM_043-2x3B
VHDI	2x3_352

ROC ROC wafer Label

ROC0 W18_XJ4KT3FT 54D

ROC1 W18_XJ4KT3FT 54B

ROC2 W18_XJ4KT3FT 54A

ROC3 W18_XJ4KT3FT 48A

ROC4 W18_XJ4KT3FT 48B

ROC5 W18_XJ4KT3FT 49A

ROC	ROC wafer	Label
ROC0	W18_XJ4KT3FT	54D
ROC1	W18_XJ4KT3FT	54B
ROC2	W18_XJ4KT3FT	54A
ROC3	W18_XJ4KT3FT	48A
ROC4	W18_XJ4KT3FT	48B
ROC5	W18_XJ4KT3FT	49A

Inspected by Arndt Kirk on date 11/8/2006

LR_dev 0.080

LL_dev 0.094

FINAL COMMENT by Arndt Kirk No assembly problems. No wirebond problem.

PLAQUETTE made READY for testing on 11/8/2006 by Arndt Kirk

PLAQUETTE TESTED on 2006-11-09 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	144	171	144	137	165	158
Vana	139	127	118	125	130	135
Cal_Del	87	67	81	96	82	74
Vthrs_Comp	73	83	84	74	81	83
Unbumped	0	0	0	1	0	0
Dead	0	0	0	0	0	0
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	0	0	0	1	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-13
