Sensor: S_1x5L_09, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W19_XN4K38T | 67C |
| ROC1 | W19_XN4K38T | 67A |
| ROC2 | W19_XN4K38T | 06B |
| ROC3 | W19_XN4K38T | 66A |
| ROC4 | W19_XN4K38T | 65D |
| Ibias_DAC, Ibias_DAC Data | 138 | 144 | 141 | 135 | 144 |
| Vana, VanaData | 122 | 133 | 127 | 128 | 133 |
| CalDelData and plots | 99 | 66 | 78 | 102 | 79 |
| VthrCompData and plots | 75 | 90 | 83 | 83 | 70 | Depletion Voltage is -10 and suggested operational voltage is -50
| TestDdata ,TestD Plots | 0 | 0 | 1 | 0 | 0 |
| LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): Bad laser test. Retesting.
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 4:11 PM
