Sensor: S_1x5L_08, Data for leakage current measurement , and plot on overall it is a BAD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W32_XA4K5NT | 63D |
| ROC1 | W32_XA4K5NT | 63A |
| ROC2 | W32_XA4K5NT | 62C |
| ROC3 | W32_XA4K5NT | 62B |
| ROC4 | W32_XA4K5NT | 61D |
| Ibias_DAC, Ibias_DAC Data | 146 | 139 | 141 | 129 | 144 |
| Vana, VanaData | 147 | 141 | 138 | 127 | 121 |
| CalDelData and plots | 87 | 82 | 83 | 82 | 81 |
| VthrCompData and plots | 83 | 81 | 82 | 67 | 68 | Depletion Voltage is -50 and suggested operational voltage is -90
| TestDdata ,TestD Plots | 0 | 3 | 41 | 5 | 1 |
| LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD | BAD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): still 50 dead pixels.
This Device have been tested 1Times prior to this one and here are the links to the previous tests:End testing time: 2:43 PM
