Sensor: S_1x2T_90, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | UNKNOWN | UNKNOWN |
| ROC1 | UNKNOWN | UNKNOWN |
| Ibias_DAC, Ibias_DAC Data | 172 | 168 |
| Vana, VanaData | 156 | 133 |
| CalDelData and plots | 57 | 79 |
| VthrCompData and plots | 90 | 74 | Depletion Voltage is -236 and suggested operational voltage is -276
| TestDdata ,TestD Plots | 1 | 10 |
| LightData ,Light Plots | 1 | 1 |
| Pass/Fail TestD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD |
Noise MAP at VMAX
![[IMAGE] of](P_1x2T_903_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2T_903_C-580-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 95 | 115 |
| Vsf | 155 | 140 |
| VoffsetOp | 125 | 90 |
| VIbias_PH | 100 | 95 |
| ROC0 NOISE | ![[IMAGE] of](P_1x2T_903_C-580-noise-ROC0-MAP.jpg) | ![[IMAGE] of](P_1x2T_903_C-580-noise-ROC0-HISTO.jpg) | MEAN = 3.397802SIGMA = 0.259431 |
| ROC1 NOISE | ![[IMAGE] of](P_1x2T_903_C-580-noise-ROC1-MAP.jpg) | ![[IMAGE] of](P_1x2T_903_C-580-noise-ROC1-HISTO.jpg) | MEAN = 4.183966SIGMA = 0.333015 |
Comment (if any):
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 1:13 PM
