Sensor: S_1x2R_08, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W20_XP4K3AT | 12B |
| ROC1 | W20_XP4K3AT | 11B |
| Ibias_DAC, Ibias_DAC Data | 141 | 129 |
| Vana, VanaData | 127 | 135 |
| CalDelData and plots | 85 | 90 |
| VthrCompData and plots | 71 | 65 | Depletion Voltage is -44 and suggested operational voltage is -84
| TestDdata ,TestD Plots | 0 | 0 |
| LightData ,Light Plots | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD |
Comment (if any): All good.
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 3:11 PM
