Sensor: S_1x2L_17, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | KNN0GDT | 66C |
| ROC1 | KNN0GDT | 66D |
| Ibias_DAC, Ibias_DAC Data | 144 | 142 |
| Vana, VanaData | 130 | 133 |
| CalDelData and plots | 75 | 92 |
| VthrCompData and plots | 80 | 78 | Depletion Voltage is -46 and suggested operational voltage is -86
| TestDdata ,TestD Plots | 0 | 0 |
| LightData ,Light Plots | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD |
Noise MAP
![[IMAGE] of](P_1x2L_177_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2L_177_C-580-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 105 | 105 |
| Vsf | 135 | 140 |
| VoffsetOp | 85 | 75 |
| VIbias_PH | 100 | 100 |
| ROC0 NOISE | ![[IMAGE] of](P_1x2L_177_C-580-noise-ROC0-MAP.jpg) | ![[IMAGE] of](P_1x2L_177_C-580-noise-ROC0-HISTO.jpg) | MEAN = 4.716033SIGMA = 0.357587 |
| ROC1 NOISE | ![[IMAGE] of](P_1x2L_177_C-580-noise-ROC1-MAP.jpg) | ![[IMAGE] of](P_1x2L_177_C-580-noise-ROC1-HISTO.jpg) | MEAN = 4.808774SIGMA = 0.384511 |
Comment (if any): good!
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 1:13 PM
