![[IMAGE] of](P_1x2L_148_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x2L_148_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 44 V |
| Operational Voltage 84 V |
Parts committed by Bolla Gino on date 2/23/2007
| Part | ID |
|---|---|
| BBM | BBM_148-1x2T |
| VHDI | 1x2L_247 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W29_X64K5ST | 29D |
| ROC1 | W29_X64K5ST | 29B |
Inspected by Lockwood Gale on date 2/28/2007
| LR_dev | 0.105 |
| LL_dev | 0.102 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebond problem. |
PLAQUETTE made READY for ENCAPSULATION on 2/28/2007 by Lockwood Gale
PLAQUETTE encapsulated on 3/1/2007 by Arndt Kirk
PLAQUETTE made READY for testing on 3/1/2007 by Arndt Kirk
P_1x2L_148_Aon 3/2/2007 10:17 AM
P_1x2L_148_A-1on 3/2/2007 10:46 AM
P_1x2L_148_A-2on 3/2/2007 11:06 AM
P_1x2L_148_A-3on 3/2/2007 3:19 PM
P_1x2L_148_A-3on 3/2/2007 3:19 PM
PLAQUETTE TESTED on 2007-03-02 by Isaac Childres
|
|
|||
|
|
| ROC | ROC0 | ROC1 | |
| Ibias_DAC | 122 | 152 | |
| Vana | 125 | 144 | |
| Cal_Del | 89 | 76 | |
| Vthrs_Comp | 80 | 78 | |
| Unbumped | 0 | 0 | |
| Dead | 0 | 0 | |
| Noisy | 0 | 0 | |
| Undecoded | 0 | 0 | |
| Total BAD | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x2L_148_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x2L_148_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x2L_148_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x2L_148_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x2L_148_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x2L_148_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 145 | 90 |
| Vsf | 135 | 145 |
| VoffsetOp | 60 | 110 |
| VIbias_PH | 105 | 105 |
Noise MAP
![[IMAGE] of](P_1x2L_148_A-3-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2L_148_A-3-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
