P_1x2L_091_A

Parts committed by Bolla Gino on date 11/15/2006

PartID
BBMBBM_091-1x2T
VHDI1x2L_206

ROCROC waferLabel
ROC0W20_XP4K3AT49B
ROC1W20_XP4K3AT49C

Inspected by Lockwood Gale on date 11/21/2006
LR_dev0.093
LL_dev0.096
FINAL COMMENT by Lockwood GaleNo assembly problems No wirebonding problems.

PLAQUETTE made READY for testing on 11/21/2006 by Lockwood Gale

P_1x2L_091_Aon 11/21/2006 3:41 PM

PLAQUETTE TESTED on 2006-11-21 by Isaac Childres

[IMAGE] of
IV_XML-File
Maximum Voltage 600 V
[IMAGE] of
LASER_XML-File
Depletion Voltage 46 V
Operational Voltage 86 V

ROCROC0ROC1
Ibias_DAC135133
Vana134128
Cal_Del7974
Vthrs_Comp7277
Unbumped00
Dead00
Noisy00
Undecoded00
Total BAD00

ASSEMBLY_XML-File SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
[IMAGE] of I_BIAS_DAC_XML-File
[IMAGE] of VANA_XML-File
[IMAGE] of DEAD_XML-File
[IMAGE] of NOISY_XML-File
[IMAGE] of UNDECODED_XML-File
[IMAGE] of LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-27

Plaquette assigned to panel P4L_017
