P4R_043
Unbumped pixels are red, dead are black, noisy are yellow, and undecoded are blue
Plaquette
Position
Purdue Map
FNAL Plaq. Map
FNAL Panel Map
P_1x5L_179_A
4
P_2x4T_089_C
3
P_2x3T_010_A
2
P_1x2R_090_C
1
Panel assembly comments
9Feb07/Sudhir: This encapsulaed panel was PTA tested and light tested by Sudhir after encapsulation today
Overall panel grade:
A
