P4R_023
Unbumped pixels are red, dead are black, noisy are yellow, and undecoded are blue
Plaquette
Position
Purdue Map
FNAL Plaq. Map
FNAL Panel Map
P_1x5L_114_A
4
P_2x4T_114_A
3
P_2x3T_075_C
2
P_1x2R_114_A
1
Panel assembly comments
First production panel built by Hengbao. It looks perfect.
Overall panel grade:
A
