| Plaquette | Position | Purdue Map | FNAL Plaq. Map | FNAL Panel Map |
|---|---|---|---|---|
| P_1x5L_006_A | 4 | | | |
| P_2x4T_015_A | 3 | | | |
| P_2x3T_006_A | 2 | | | |
| P_1x2R_063_A | 1 | | | |
| Panel assembly comments |
|---|
| 14Mar07/ME: Max voltage = 480V (due to 1x5), IZM problem in 1x5 ROCs 1 and 3 (0.9% total bad pixels on 1x5) 19apr07/ME: Upgrade to A- |
