P4L_029
Unbumped pixels are red, dead are black, noisy are yellow, and undecoded are blue
Plaquette
Position
Purdue Map
FNAL Plaq. Map
FNAL Panel Map
P_1x5R_148_A
4
P_2x4B_104_A
3
P_2x3T_102_A
2
P_1x2L_101_A
1
Panel assembly comments
Overall panel grade:
A
