P3R_013
Unbumped pixels are red, dead are black, noisy are yellow, and undecoded are blue
Plaquette
Position
Purdue Map
FNAL Plaq. Map
FNAL Panel Map
P_2x5_084_C
3
P_2x4B_094_A
2
P_2x3B_026_C
1
Panel assembly comments
6Feb07: This encapsulated panel is PTA tested and light tested after encapsulation by Hengbao Zeng
Overall panel grade:
A
