| Plaquette | Position | Purdue Map | FNAL Plaq. Map | FNAL Panel Map |
|---|---|---|---|---|
| P_2x5_004_C | 3 | | | |
| P_2x4B_028_C | 2 | | | |
| P_2x3B_171_A | 1 | | | |
| Panel assembly comments |
|---|
| The 2x4 plaquette was bowing up on the upper edge. Three drops of epoxy Araldite 2011 were applied to secure the plaquette on that edge and to stop any further opening of the gap underneath. |
