| Part | Description | Qty | Acquired | Order info |
|---|---|---|---|---|
| 100EL11 | ECL 1:2 fanout | 1 | x | |
| 100ELT24 | TTL-ECL translator | 2 | x | |
| 100ELT25 | ECL-TTL translator | 1 | x | |
| HFA3102 | RF transistor array | 1 | NO | |
| Trompeter CBBJR79 | Triaxial connector | 4 | x | |
| Amphenol 31-5431 | BNC connector | 3 | x | |
| LM317T | Positive regulator | 1 | x | |
| LM337T | Negative regulator | 2 | x | |
| MC7805CT | Positive 5V regulator | 1 | x | |
| CML 5693F1;1;1 | LED assembly | 1 | x | Digi-Key L2045111-ND |
| 0.01 uF, 50 V | Capacitor | 21 | x | Digi-Key 399-1158-2-ND |
| 1.0 uF, 35 V, Tant B | Capacitor | 6 | x | Digi-Key PCS6105CT-ND |
| 4.7 uF, 20 V, Tant B | Capacitor | 1 | x | Digi-Key 399-1612-1-ND |
| 51.1 | Resistor | 6 | x | Digi-Key 311-51.1CTR-ND |
| 120 | Resistor | 5 | x | Digi-Key 311-120CCT-ND |
| 390 | Resistor | 2 | x | Digi-Key 311-390CCT-ND |
| 240 | Resistor | 1 | x | Digi-Key 311-240CCT-ND |
| 75 | Resistor | 1 | x | Digi-Key 311-75.0CCT-ND |
| 10K | Resistor | 2 | x | Digi-Key 311-10.0KCTR-ND |
| 1M | Resistor | 1 | x | Digi-Key 311-1.00MCCT-ND |
| 1K | Resistor | 2 | x | Digi-Key 311-1.00KCCT-ND |
| 124 | Resistor | 1 | NO | Digi-Key 311-124CCT-ND |
| 24 | Resistor | 4 | NO | Digi-Key 311-24.0CCT-ND |
| 1.2K | Resistor | 1 | NO | Digi-Key 311-1.20KCCT-ND |
| 1.4K | Resistor | 1 | NO | Digi-Key 311-1.40KCCT-ND |
| 40-pin header | 1 | Digi-Key 2-102973-0-ND |
|
|
|
|
|
|
|
|
|
