Plaquettes in Debugging |
|
|
|
Click on a device ID to see that device's page |
|
Number |
Plaquette ID |
Reason |
|
1 |
P_1x5R_031_A |
Too many disconnected channels
due to bending (some introduced to understand the bending issue). Opened to
inspect broken pixels. |
|
2 |
P_1x5R_125_C |
Rework at RTI did NOT go well |
|
3 |
P_2x3B_031_A |
ROC5 has a bad ROW. POTENTIAL
REWORK with IZM |
|
4 |
P_2x3B_058_C |
HV trouble. To be irradiated |
|
5 |
P_2x3B_063_A |
WASTED to understand IZM problem |
|
6 |
P_2x3B_095_A |
ALL ROCs with IZM problem. But
good IV. To be irradiated |
|
7 |
P_2x3B_111_C |
HV trouble. To be irradiated |
|
8 |
P_2x3T_026_C |
Rework at RTI did NOT go well |
|
9 |
P_2x3T_031_A |
HV trouble. To be irradiated |
|
10 |
P_2x3T_122_C |
HV trouble. To be irradiated |
|
11 |
P_2x3T_137_A |
ROC2 has troubles and it is
bypassed. POTENTIAL REWORK with IZM |
|
12 |
P_2x4T_026_C |
Rework at RTI did NOT go well |
|
13 |
P_2x4T_041_C |
Rework at RTI did NOT go well |
|
14 |
P_2x4T_045_C |
BAD BAD HV. Unrecoverable.
Opened to inspect NOISY area. |
|
15 |
P_2x4T_094_A |
Rework at IZM did NOT go well |
|
16 |
P_2x4T_176_C |
Sensor came OFF during assembly |
|
17 |
P_2x5_024_C |
6 ROCS detached during assembly |
|
18 |
P_2x5_079_A |
Still one ROC does not work
after rework at IZM. It is a different ROC from the one that was replaced. |
|
19 |
P_2x5_098_A |
Too many disconnected channels
after IZM rework |
|
20 |
P_2x5_158_A |
BAD SENSOR (opened and found
mech damage) |
|
|
|
Last updated on: 10/29/2007 at 9:35 AM |
|
|
|
|
